NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor

NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor
NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor
Basic Information
Place of Origin: Shanghai, China
Brand Name: ZONCN
Certification: CE
Model Number: NZ200T-37GY-4-24V
Document: NZ200T parameter list.pdf
Minimum Order Quantity: 1 unit
Packaging Details: Carton Packing
Delivery Time: 7-30 work days
Payment Terms: T/T,Western Union，Paypal
Supply Ability: 100000 units per month
Get Best Price Contact Now
Application: Air Compressors Power: 37KW Vfd
Voltage: 380V Input And Output Input: 3phase 50/60Hz
Output: 3phase 0-320Hz Display: LED Display
Brake Unit: Optional DC Braking: Yes
Certificates: CE Compressor Controller Dimensions: 4.3/7/10 Inches
Communication: Modbus Type: AC Drives Vfd
Highlight:

37KW Industry Specific Inverter

,

Industry Specific Inverter Ac Drives

,

Industry Specific Compressor Vfd Inverter

NZ200T-37GY-4-24V Inverter Vfd Motor Drives For Air Compressor


Product description:

NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor 0

· Open loop vector control vfd inverter,VF control

· Overload capacity is 60s for 150% of rate current,3s for 180% of rate current.

· High performance; environmental adaptation

· Simple structure; Compact size; Easy install

· Economic vector control inverter, high torque output, motor runs smoothly when heavy loading

· Protection function: Output phase loss protection,Over-current protection, Over-voltage protection,Overload protection, Over-heat protection etc.

NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor 1


Product model specification:

Type Input voltage Rated output power(KW) Rated input current(A) Rated output current (A) Motor power ( KW)
NZ200T-0R4G-2


AC 220V


 0.4 5.4 2.5 0.4
NZ200T-0R75G-2 0.75 7.2 5.0 0.75
NZ200T-1R5G-2 1.5 10.0 7.0 1.5
NZ200T-2R2G-2 2.2 16 11 2.2
NZ200T-3R7G-2 3.7 24 16.5 3.7
NZ200T-0R4G-4












AC 380V



















 0.4 3.4 1.2 0.4
NZ200T-0R75G-4 0.75 3.8 2.5 0.75
NZ200T-1R5G-4 1.5 5.0 3.7 1.5
NZ200T-2R2G-4 2.2 5.8 5.0 2.2
NZ200T-3R7G/5R5P-4 3.7/5.5 10/15 9/13 3.7/5.5
NZ200T-5R5G/7R5P-4 5.5/7.5 15/20 13/27 5.5/7.5
NZ200T-7R5G/11P-4 7.5/11 20/26 17/25 7.5/11
NZ200T-11G/15P-4 11/15 26/35 25/32 11/15
NZ200T-15G/18.5P-4 15/18.5 35/38 32/37 15/18.5
NZ200T-18.5G/22P-4 18.5/22 38/46 37/45 18.5/22
NZ200T-22G/30P-4 22/30 46/62 45/60 22/30
NZ200T-30G/37P-4 30/37 62/76 60/75 30/37
NZ200T-37G/45P-4 37/45 76/90 75/90 37/45
NZ200T-45G/55P-4 45/55 90/105 90/110 45/55
NZ200T-55G-4 55 105 110 55
NZ200T-75P-4 75 140 150 75
NZ200T-75G/90P-4 75/90 140/160 150/176 75/90
NZ200T-90G/110P-4 90/110 160/210 176/210 90/110
NZ200T-110G/132P-4 110/132 210/240 210/253 110/132
NZ200T-132G/160P-4 132/160 240/290 253/300 132/160
NZ200T-160G/185P-4 160/185 290/330 300/340 160/185
NZ200T-185G/200P-4 185/200 330/370 340/380 185/200
NZ200T-200G/220P-4 200/220 370/410 380/420 200/220
NZ200T-220G/250P-4 220/250 410/460 420/470 220/250
NZ200T-250G/280P-4 250/280 460/500 470/520 250/280
NZ200T-280G/315P-4 280/315 500/580 520/600 280/315
NZ200T-315G/350P-4 315/350 580/620 600/640 315/350
NZ200T-350G/400P-4 350/400 620/670 640/690 350/400
NZ200T-400G/450P-4 400/450 670/790 690/790 400/450


Product application:

NZ200T-37GY-4-24V 37KW Vfd Inverter Ac Drives Industry Specific For Compressor 2

In the field of air compressors, the ZONCN NZ200T series inverter is the ideal partner. It can accurately match the operation needs of the air compressor, whether it is the requirements of smoothness when starting, or the flexible control of the speed during operation, the series of inverter can easily cope with. Its advanced control technology can optimize the working efficiency of the air compressor and achieve energy saving and consumption reduction. At the same time, the ZONCN NZ200T series inverter debugging is simple and convenient, even non-professionals can quickly complete the setup and put into use. Moreover, with reliable quality, it greatly reduces the failure rate during the operation of the air compressor, ensuring the stable operation of the equipment for a long time, and providing solid and powerful support for your production operations.


FAQ:

Q1:What is your MOQ?
A: 1 pc


Q2:What's your terms of payment?
A:T/T 100% before delivery.


Q3:What's your delivery time?
A:Generally within ten days after receiving full payment.


Q4:How can l get OEM/ODM order?
A:If your order quantity meets certain requirements, we are happy to customize it for you. We have cooperation with more than forty manufacturers.


Tag:

3 Phase Motor Vfd,

Single Phase Vfd,

3 Phase Vfd
