NZ200T-18.5GY-4-24V Industry Specific Inverter 380V 18.5KW Permanent Magnet

NZ200T-18.5GY-4-24V Industry Specific Inverter 380V 18.5KW Permanent Magnet
NZ200T-18.5GY-4-24V Industry Specific Inverter 380V 18.5KW Permanent Magnet NZ200T-18.5GY-4-24V Industry Specific Inverter 380V 18.5KW Permanent Magnet NZ200T-18.5GY-4-24V Industry Specific Inverter 380V 18.5KW Permanent Magnet
Basic Information
Place of Origin: Shanghai, China
Brand Name: ZONCN
Certification: CE
Model Number: NZ200T-18.5GY-4-24V
Minimum Order Quantity: 1 unit
Packaging Details: Carton Packing
Delivery Time: 7-30 work days
Payment Terms: T/T, Western Union，Paypal
Supply Ability: 100000 units per month
Get Best Price Contact Now
Application: Air Compressors Power: 18.5KW
Voltage: 380V Input: 3phase 50/60Hz
Output: 3phase 0-320Hz Display: LED
Highlight:

Industry Specific Inverter 380V 18.5KW

,

Industry Specific Inverter Permanent Magnet

NZ200T-18.5GY-4-24V 380V 18.5KW Permanent Magnet Synchronization Vfd Industry Specific Inverter

NZ200T-18.5GY-4-24V AC Drives For Air Compressor



Product Introduction:

The NZ200T series variable frequency drives are specifically designed for permanent magnet synchronous motors, offering several advantages. These drives feature a simple terminal design, allowing for easy and hassle-free wiring. Additionally, the NZ200T series drives are known for their straightforward and simple debugging process.



These drives are particularly suitable for air compressors, providing efficient control and operation. To enhance control capabilities, we also offer compatible HMI controllers. The NZ200T series drives deliver high torque output, ensuring smooth motor startup even under heavy loads. Moreover, they are equipped with various protection functions, guaranteeing energy efficiency and safety.



In summary, the NZ200T series variable frequency drives are an excellent choice for applications involving permanent magnet synchronous motors. With their simple terminal design, easy debugging process, compatibility with air compressors, and the availability of HMI controllers, these drives offer high torque output and a range of protection features, ensuring both energy efficiency and safety.





Product model specification:

Type Input voltage Rated output power(KW) Rated input current(A) Rated output current (A) Motor power ( KW)
NZ200T-0R4G-2



AC 220V



 0.4 5.4 2.5 0.4
NZ200T-0R75G-2 0.75 7.2 5.0 0.75
NZ200T-1R5G-2 1.5 10.0 7.0 1.5
NZ200T-2R2G-2 2.2 16 11 2.2
NZ200T-3R7G-2 3.7 24 16.5 3.7
NZ200T-0R4G-4























AC 380V





































 0.4 3.4 1.2 0.4
NZ200T-0R75G-4 0.75 3.8 2.5 0.75
NZ200T-1R5G-4 1.5 5.0 3.7 1.5
NZ200T-2R2G-4 2.2 5.8 5.0 2.2
NZ200T-3R7G/5R5P-4 3.7/5.5 10/15 9/13 3.7/5.5
NZ200T-5R5G/7R5P-4 5.5/7.5 15/20 13/27 5.5/7.5
NZ200T-7R5G/11P-4 7.5/11 20/26 17/25 7.5/11
NZ200T-11G/15P-4 11/15 26/35 25/32 11/15
NZ200T-15G/18.5P-4 15/18.5 35/38 32/37 15/18.5
NZ200T-18.5G/22P-4 18.5/22 38/46 37/45 18.5/22
NZ200T-22G/30P-4 22/30 46/62 45/60 22/30
NZ200T-30G/37P-4 30/37 62/76 60/75 30/37
NZ200T-37G/45P-4 37/45 76/90 75/90 37/45
NZ200T-45G/55P-4 45/55 90/105 90/110 45/55
NZ200T-55G-4 55 105 110 55
NZ200T-75P-4 75 140 150 75
NZ200T-75G/90P-4 75/90 140/160 150/176 75/90
NZ200T-90G/110P-4 90/110 160/210 176/210 90/110
NZ200T-110G/132P-4 110/132 210/240 210/253 110/132
NZ200T-132G/160P-4 132/160 240/290 253/300 132/160
NZ200T-160G/185P-4 160/185 290/330 300/340 160/185
NZ200T-185G/200P-4 185/200 330/370 340/380 185/200
NZ200T-200G/220P-4 200/220 370/410 380/420 200/220
NZ200T-220G/250P-4 220/250 410/460 420/470 220/250
NZ200T-250G/280P-4 250/280 460/500 470/520 250/280
NZ200T-280G/315P-4 280/315 500/580 520/600 280/315
NZ200T-315G/350P-4 315/350 580/620 600/640 315/350
NZ200T-350G/400P-4 350/400 620/670 640/690 350/400
NZ200T-400G/450P-4 400/450 670/790 690/790 400/450





Product application:

NZ200T-18.5GY-4-24V Industry Specific Inverter 380V 18.5KW Permanent Magnet 0

ZONCN NZ200T series inverter has significant application advantages in the field of air compressors and has a strong market prospect. Designed to meet the specific needs of air compressors, these converters offer the following advantages:



Strong applicability: NZ200T series inverter can be widely used in all kinds of air compressors, including screw, piston, centrifugal and so on. Whether it is a small household air compressor or a large industrial air compressor, it can be well matched and applied.



High efficiency and energy saving: These drives use advanced control algorithms and efficient motor control technology to achieve accurate motor speed regulation and load matching. By adjusting the motor speed according to the actual demand, the energy consumption can be effectively reduced and the energy saving effect can be achieved.



Large torque output: The NZ200T series inverter has a strong torque output capacity, which can smoothly start the air compressor under heavy load conditions to ensure its stable operation.



Multiple protection functions: These drives have a variety of built-in protection functions, such as overload protection and overcurrent protection.






FAQ:

Q1:What is your MOQ?
A: 1 pc



Q2:What's your terms of payment?
A:T/T 100% before delivery.



Q3:What's your delivery time?
A:Generally within ten days after receiving full payment.



Q4:How can l get OEM/ODM order?
A:If your order quantity meets certain requirements, we are happy to customize it for you. We have cooperation with more than forty manufacturers.
