380v Variable Frequency Drivers 11kw VFD Inverter

380v Variable Frequency Drivers 11kw VFD Inverter
380v Variable Frequency Drivers 11kw VFD Inverter
380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter 380v Variable Frequency Drivers 11kw VFD Inverter
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE, KC
Model Number: Z2400-11G
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T,Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: Variable Frequency Drivers Application: Industrial Applications
Brand: ZONCN Control Mode: Vector Control
Power: 11kw/15hp Braking Resitor: Optional
Braking Unit: Built-in PID Control: Built-in
Communication: RS485/EtherCAT Warranty: 18 Months
Highlight:

Variable Frequency Drivers VFD Inverter

,

11kw VFD Inverter

,

380v VFD Inverter

VFD Inverter 380v Variable Frequency Drivers 11kw

Why Choose ZONCN VS Domestic Brands?

While there are many domestic Chinese VFDs are low-cost, ZONCN delivers higher reliability, precision, and energy savings—justifying its slightly higher price for demanding applications. It’s the optimal choice for users who value long-term performance over upfront savings.

Need a technical comparison for your specific application? Let me know your requirements!

VFD Inverter Specification

 Inverter Model Rated Output Power(kW) Rated Input Current(A) Rated Output Current(A) Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z2200-0R4G 0.4 5.4 2.5 0.4
Z2200-0R75G 0.75 7.2 5 0.75
Z2200-1R5G 1.5 10 7 1.5
Z2200-2R2G 2.2 16 11 2.2
Z2200-3R7G 3.7 23 16.5 3.7
Z2200-5R5G 5.5 21 25 5.5
Z2200-7R5G 7.5 31 32 7.5
Input Voltage:3PH AC 380V±15%
Z2400-0R75G 0.75 3.8 2.5 0.75
Z2400-1R5G 1.5 5 3.7 1.5
Z2400-2R2G 2.2 5.8 5 2.2
Z2400-3R7G/5R5P 3.7/5.5 10/15.0 9/13 3.7/5.5
Z2400-5R5G 5.5 15 13 5.5
Z2400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
Z2400-11G/15P 11/15 26/35 25/32 11/15
Z2400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
Z2400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
Z2400-22G/30P 22/30 46/62 45/60 22/30
Z2400-30G/37P 30/37 62/76 60/75 30/37
Z2400-37G/45P 37/45 76/90 75/90 37/45
Z2400-45G/55P 45/55 90/105 90/110 45/55
Z2400-55G 55 105 110 55
Z2400-75G/90P 75/90 140/160 150/176 75/90
Z2400-90G/110P 90/110 160/210 176/210 90/110
Z2400-110G/132P 110/132 210/240 210/253 110/132
Z2400-132G/160P 132/160 240/290 253/300 132/160
Z2400-160G/185P 160/185 290/330 300/340 160/185
Z2400-185G/200P 185/200 330/370 340/380 185/200
Z2400-200G/220P 200/220 370/410 380/420 200/220
… 　 　 　 　




*Note: If you have any special requirements for VFD inverter, pls feel free to contact us directly, we can customize for you.





Workshop

380v Variable Frequency Drivers 11kw VFD Inverter 0

380v Variable Frequency Drivers 11kw VFD Inverter 1



Applications

  1. Industrial Machinery – Used in conveyor systems, packaging machines, and textile equipment.

  2. HVAC Systems – Controls fans, pumps, and compressors in heating, ventilation, and air conditioning systems.

  3. Water & Wastewater Treatment – Regulates pumps and blowers in water supply and sewage treatment plants.

  4. Mining & Metallurgy – Powers crushers, conveyors, and ventilation systems in mining operations.

  5. Oil & Gas – Optimizes pumps and compressors in extraction and pipeline systems.

  6. Building Automation – Integrates with elevators, escalators, and smart building systems

  7. Food & Beverage – Controls mixers, extruders, and bottling lines for efficient production.

  8. Plastics & Rubber – Drives injection molding machines and extruders.

  9. Material Handling – Used in cranes, hoists, and automated storage/retrieval systems.

The Z2000 series is known for its energy efficiency, precise motor control, and adaptability across various industries. Let me know if you need details on specific functions!
