Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: KC; CE
Model Number: Z2400-7R5G
Minimum Order Quantity: 1 PC
Price: netigotable
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T,Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: VFD Inverter Brand: ZONCN
Voltage: 220V/380V/440v/480v Power Range: 0.4kw-450kw
Rated Power: 11KW/15HP Communication: RS485 Modbus
Extend Keyboard: Available Delivery Time: Within 15 Days Normally
Warranty: 18 Months Certificate: CE
Highlight:

25hp ZONCN VFD Inverter

,

11kw ZONCN VFD Inverter

,

7.5kw ZONCN VFD Inverter

ZONCN VFD Inverter 5.5kw 7.5kw 11kw Variable Speed Drives 7hp 10hp 25hp Variadores


The ZONCN VFD Z2000 is a Variable Frequency Drive (VFD) designed for controlling the speed of AC motors. Here are some potential advantages of the ZONCN VFD Z2000, based on general features commonly found in VFDs of this type:

  1. Energy Efficiency: Z2000 VFD can significantly reduce energy consumption by adjusting the motor speed to match the load requirements, which is particularly beneficial in applications where the load varies.

  2. Precise Speed Control: The Z2000 VFD offers precise control over motor speed, which can improve process control and product quality in various industrial applications.

  3. Soft Start and Stop: The ability to gradually start and stop motors reduces mechanical stress on the motor and connected equipment, potentially extending their lifespan.

  4. Reduced Maintenance: By controlling the motor speed and reducing mechanical and electrical stress, the Z2000 can help lower maintenance costs and downtime.

  5. Improved Process Control: Enhanced control over motor operations can lead to better process outcomes, especially in applications requiring precise speed adjustments.

  6. Protection Features: The Z2000 probably includes various protection features such as overvoltage, undervoltage, overcurrent, and overtemperature protection, which help safeguard the motor and drive from damage.

  7. Compatibility: It is probably compatible with a wide range of motors and can be used in various applications, from HVAC systems to industrial machinery.

  8. Wide Range of Applications: Suitable for a variety of applications, including pumps, fans, conveyors, and more, making it a versatile choice for many industries.


Z2000 Inverter Advantages


High reliability: suitable for industrial environments.
Energy saving and efficient: Optimize motor operation and reduce energy consumption.
Flexible configuration: adaptable to various application requirements



Z2000 inverter Specification


                    Item                                ZONCN Z2000 Series Inverter
Standard Function Control mode Senseless flux vector control(SFVC) ; Voltage/Frequency (V/F) control
Maximum frequency Vector control: 0-320Hz ; V/F control: 0-3200Hz
Carrier frequency 1-16kHz ; The carrier frequency is automatically adjusted based on the load features
Input frequency solution Digital setting: 0.01Hz ; Analog setting: maximum frequency x 0.025%
Startup torque G type: 0.5Hz/150%(SFVC) ; P type: 0.5Hz/100%
Speed range 1:100
Speed stability accuracy ±0.5%
Overload capacity G type: 60s for 150% of the rated current, 3s for 180% of the rated current. P type: 60s for 120% of the rated current, 3s for 150% of the rated current.
Torque boost Auto boost ; Customized boost 0.1%-30.0%
V/F curve Line V/F curve; Multi-point V/F curve; N-power V/F curve
V/F separation Two types: complete separation; half separation
Ramp mode Straight-line ramp ; S-curve ramp ; Four groups of acceleration/deceleration time with the range of 0.0-6500.0s
DC braking DC braking frequency : 0.0Hz to maximum frequency Braking time: 0.0~100.0s Braking action current value: 0.0%~100.0%
JOG control JOG frequency range: 0.00~50.00Hz JOG acceleration/deceleration time: 0.0~6500.0s
Onboard multiple preset speeds It implements up to 16 speeds via the simple PLC function or combination of X terminal states.
Onboard PID It realizes process-controlled closed loop control system easily
Auto voltage regulation(AVR) It can keep constant output voltage automatically when the mains voltage changes.
Auto voltage/ Over current stall control The current and voltage are limited automatically during the running process so as to avoid frequent tripping due to overvoltage/over current
Rapid current limit It helps to avoid frequent over current faults of the AC drive
Torque limit and control It can keep constant output voltage automatically when the mains voltage changes

Z2000 Inverter Specification

Inverter Model Rated Output Power(kW) Rated Input Current(A) Rated Output Current(A) Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z2200-0R4G 0.4 5.4 2.5 0.4
Z2200-0R75G 0.75 7.2 5 0.75
Z2200-1R5G 1.5 10 7 1.5
Z2200-2R2G 2.2 16 11 2.2
Z2200-3R7G 3.7 23 16.5 3.7
Z2200-5R5G 5.5 21 25 5.5
Z2200-7R5G 7.5 31 32 7.5
Input Voltage:3PH AC 380V±15%
Z2400-0R75G 0.75 3.8 2.5 0.75
Z2400-1R5G 1.5 5 3.7 1.5
Z2400-2R2G 2.2 5.8 5 2.2
Z2400-3R7G/5R5P 3.7/5.5 10/15.0 9/13 3.7/5.5
Z2400-5R5G 5.5 15 13 5.5
Z2400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
Z2400-11G/15P 11/15 26/35 25/32 11/15
Z2400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
Z2400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
Z2400-22G/30P 22/30 46/62 45/60 22/30
Z2400-30G/37P 30/37 62/76 60/75 30/37
Z2400-37G/45P 37/45 76/90 75/90 37/45
Z2400-45G/55P 45/55 90/105 90/110 45/55
Z2400-55G 55 105 110 55
Z2400-75G/90P 75/90 140/160 150/176 75/90
Z2400-90G/110P 90/110 160/210 176/210 90/110
Z2400-110G/132P 110/132 210/240 210/253 110/132
Z2400-132G/160P 132/160 240/290 253/300 132/160
Z2400-160G/185P 160/185 290/330 300/340 160/185
Z2400-185G/200P 185/200 330/370 340/380 185/200
Z2400-200G/220P 200/220 370/410 380/420 200/220
… 　 　 　 　


Z2000 Inverter Applications


ZONCN VFD Inverter 5.5kw 7.5kw 11kw Variable Speed Drives 7hp 10hp 25hp Variadores 0
