220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD

220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD
220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE
Model Number: Z8200-3R7G
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: AC Inverters Product Name: VFD Inverter
Brand: ZONCN Series: Z8000 High Performance Series
Input Voltage: 220v 380v 690v Control Mode: V/F Control
Control Mode: Cloose Loop Vector Control Communication: RS485/Profibus
Tension Control: Yes
Highlight:

3.7kw Inverter

,

220v Inverter

,

5hp Inverter

220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD







Z8000 VFD Introduction





Z8000 VFD is ZONCN's high performance VFD series, except 220v and 380v input voltage, this series also have 660-690v, the power range for this series is from 0.4kw-1000kw.



Z8000 series VFD is V/F control, open loop vector control and close loop vector control, it also has tension control.



Z8000 series VFD not only support standard RS485 communication, but also Profibus communication.



Z8000 series VFD also support Permanent magnet synchronous motor.



Z8000 VFD Specification

VFD Model Rated Output Power(kW) Rated Input Current(A) Rated Output Current(A) Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z8200-0R4G 0.4 5.4 2.5 0.4
Z8200-0R75G 0.75 7.2 5 0.75
Z8200-1R5G 1.5 10 7 1.5
Z8200-2R2G 2.2 16 11 2.2
Z8200-3R7G 3.7 23 16.5 3.7
Input Voltage:3PH AC 380V±15%
Z8400-0R75G 0.75 3.8 2.5 0.75
Z8400-1R5G 1.5 5 3.7 1.5
Z8400-2R2G 2.2 5.8 5 2.2
Z8400-3R7G/5R5P 3.7/5.5 10/15.0 9/13 3.7/5.5
Z8400-5R5G/7R5P 5.5 15 13 5.5
Z8400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
Z8400-11G/15P 11/15 26/35 25/32 11/15
Z8400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
Z8400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
Z8400-22G/30P 22/30 46/62 45/60 22/30
Z8400-30G/37P 30/37 62/76 60/75 30/37
Z8400-37G/45P 37/45 76/90 75/90 37/45
Z8400-45G/55P 45/55 90/105 90/110 45/55
Z8400-55G 55 105 110 55
Z8400-75G/90P 75/90 140/160 150/176 75/90
Z8400-90G/110P 90/110 160/210 176/210 90/110
Z8400-110G/132P 110/132 210/240 210/253 110/132
Z8400-132G/160P 132/160 240/290 253/300 132/160
Z8400-160G/185P 160/185 290/330 300/340 160/185
Z8400-185G/200P 185/200 330/370 340/380 185/200
Z8400-200G/220P 200/220 370/410 380/420 200/220
… 　 　 　 　
Z8400-1000G 1000 1800 1720 1000




VFD Nameplate Description

220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 0




ZONCN Company Profile

220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 1

220v Single Phase 3.7kw Inverter Three Phase 380v Frequency Converter 5hp VFD 2




FAQ

Q1. This Z8000 series VFD can used for industrial washing machine?

A: Yes, this Z8000 series used a lot in industry washing machines.



Q2. This Z8000 series VFD can work for 660-690v input?

A. Yes, Z8000 series VFD not only have 220v/380v, but also 660v-690v.



Q3. What kinds of communication does this Z8000 series VFD support?

A.  ZONCN Z8000 series VFD support RS485 and profibus communication.
