3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter

3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter
3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE
Model Number: Z8200-3R7G
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: AC Inverters Product Name: VFD Inverter
Brand: ZONCN Series: Z8000 High Performance Series
Input Voltage: 220v 380v 690v Control Mode: Cloose Loop Vector Control
Communication: Profibus
Highlight:

220v VFD

,

380v VFD

,

3.7kw VFD

3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter







Z8000 Inverter Introduction

  • High peformance loos loop vector control
  • V/F control, on board PID control
  • wide range of frequency, can adapt to most applications
  • The carrier frequency is automatically adjusted based on the load features
  • Modbus communication
  • Support for various PG card
  • Tension control
  • Support for PM motor
  • Power range:
  • 220v 0.4kw-7.5kw
  • 380v 0.75kw-1000kw
  • 690v 11kw-1000kw



Z8000 Inverter Specification

Inverter ModelRated Output Power(kW)Rated Input Current(A)Rated Output Current(A)Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z8200-0R4G0.45.42.50.4
Z8200-0R75G0.757.250.75
Z8200-1R5G1.51071.5
Z8200-2R2G2.216112.2
Z8200-3R7G3.72316.53.7
Input Voltage:3PH AC 380V±15%
Z8400-0R75G0.753.82.50.75
Z8400-1R5G1.553.71.5
Z8400-2R2G2.25.852.2
Z8400-3R7G/5R5P3.7/5.510/15.09/133.7/5.5
Z8400-5R5G/7R5P5.515135.5
Z8400-7R5G/11P7.5/1120/2617/257.5/11
Z8400-11G/15P11/1526/3525/3211/15
Z8400-15G/18.5P15/18.535/3832/3715/18.5
Z8400-18.5G/22P18.5/2238/4637/4518.5/22
Z8400-22G/30P22/3046/6245/6022/30
Z8400-30G/37P30/3762/7660/7530/37
Z8400-37G/45P37/4576/9075/9037/45
Z8400-45G/55P45/5590/10590/11045/55
Z8400-55G5510511055
Z8400-75G/90P75/90140/160150/17675/90
Z8400-90G/110P90/110160/210176/21090/110
Z8400-110G/132P110/132210/240210/253110/132
Z8400-132G/160P132/160240/290253/300132/160
Z8400-160G/185P160/185290/330300/340160/185
Z8400-185G/200P185/200330/370340/380185/200
Z8400-200G/220P200/220370/410380/420200/220
…　　　　
Z8400-1000G1000180017201000




Inverter Nameplate Description

3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 0




ZONCN Company Profile

3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 1

3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 2




Inverter Wiring Diagram

3.7kw VFD 220v 380v Three Phase Variable Speed Drive VSD Frequency Inverter 3
