380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485

380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485
380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485
380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE
Model Number: NZ200-22G-4
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, L/C, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: VFD Inverter Product Name: Variable Frequency Inverter
Brand: ZONCN Model: NZ200-22G-4 （NZ200T-22GY-4）
Voltage: 380v+/-50% Power: 30HP/22KW
Application: Synchronous And Asynchronous Motor Delivery Time: Within 15 Days Normally
Warranty: 18 Months After Delivery OEM: Support
Highlight:

380v AC Drives

,

22kw AC Drives

,

50hz AC Drives

380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485





VFD inverter Specification

NZ100 inverter Model Input Voltage (V) Rated output power ( KW) Rated input current(A) Rated output current (A) Motor power ( KW)
NZ200-0R4G-2 1PH 220V±15% 0.4 5.4 2.5 0.4
NZ200-0R75G-2 0.75 7.2 5 0.75
NZ200-1R5G-2 1.5 10 7 1.5
NZ200-2R2G-2 2.2 16 11 2.2
NZ200-3R7G-2 3.7 17 16.5 3.7
NZ200-0R4G-4 3PH 380V±15% 0.4 3.4 1.2 0.4
NZ200-0R75G-4 0.75 3.8 2.5 0.75
NZ200-1R5G-4 1.5 5 3.7 1.5
NZ200-2R2G-4 2.2 5.8 5 2.2
NZ200-3R7G/5R5P-4 3.7 10.7 9 3.7
NZ200-5R5G/75R5P-4 5.5 14.6 13 5.5
NZ200-7R5G/11P-4 7.5 20 17 7.5
NZ200-11G/15P-4 11 26 25 11
NZ200-15G/18.5P-4 15 35 32 15
NZ200-18.5G/22P-4 18.5 38 37 18.5
NZ200-22G/30P-4 22 46 45 22
NZ200-30G/37P-4 30 62 60 30
NZ200-37G/45P-4 37 76 75 37
NZ200-45G/55P-4 45 90 90 45
NZ200-55G-4 55 105 110 55
NZ200-75G/90P-4 75 140 150 75
NZ200-90G/110P-4 90 160 176 90
NZ200-110G/132P-4 110 210 210 110
NZ200-132G/160P-4 132 240 253 132
... ... ... ... ...
NZ200-450G/500P-4 450 790 790 450





VFD Packing

380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 0





VFD Application

380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 1



Company introduction

380v AC Drives 18.5kw 22kw Pump Inverter 30hp 50hz 60hz VFD VSD With RS485 2





FAQ

Q1:  Do you have other series of inverter for option?

A: Sure, we have Mini size inverter NZ100, generial purpose series inverter Z2000 (support EtherCAT), high performance series Z8000(support Profibus), high protection IP65 IP54 series Z5000-BF, T9000 series(support profinet), etc.





Q2: Can you customize for my own brand in your VFD inverters?

A: Sure no problem, we produced a lot for OEM brands.





Q3. Where is your VFD inverter factory?

A:  Our factory located in Shanghai and Wuhu city.
