380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory

380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory
380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory
380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE
Model Number: NZ200-22G-4
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, L/C, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: VFD Inverter Product Name: Variable Frequency Inverter
Brand: ZONCN Series: NZ200
Model: NZ200-22G-4 （NZ200T-22GY-4） Power: 30HP/22KW
Application: Synchronous And Asynchronous Motor Communication: RS485
Power Range: 0.4kw-630kw OEM: Support
Highlight:

3phase AC Drives 30hp

,

variable frequency drive for 3 phase motor

,

22kw three phase vfd

380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory





NZ200 series description

ZONCN's hot selling series NZ200, vector control inverter.



ZONCN is a leading VFD inverter manufacturer in China with almost of 2 decades of experience focusing on producing VFD drives. NZ200 series is the second generation inverter of ZONCN, NZ100 is the mini size V/F control inverter, while NZ200 is compact size open loop vector control inverter which can be used in most of the industial applications.



Besides, NZ200 series inverters have RS485 communication, 24V terminal, analog input terminals,etc.



What's more, NZ200 series inverter is the best selling inverters which used in air compressor industry in China. It both supports Asynchronous motor and Permanent magnent synchronous motor (NZ200T series).



Powers from 0.4kw to 630kw are available.



VFD Specification

VFD Model Input Voltage (V) Rated output power ( KW) Rated input current(A) Rated output current (A) Motor power ( KW)
NZ200-0R4G-2 1PH 220V±15% 0.4 5.4 2.5 0.4
NZ200-0R75G-2 0.75 7.2 5 0.75
NZ200-1R5G-2 1.5 10 7 1.5
NZ200-2R2G-2 2.2 16 11 2.2
NZ200-3R7G-2 3.7 17 16.5 3.7
NZ200-0R4G-4 3PH 380V±15% 0.4 3.4 1.2 0.4
NZ200-0R75G-4 0.75 3.8 2.5 0.75
NZ200-1R5G-4 1.5 5 3.7 1.5
NZ200-2R2G-4 2.2 5.8 5 2.2
NZ200-3R7G/5R5P-4 3.7 10.7 9 3.7
NZ200-5R5G/75R5P-4 5.5 14.6 13 5.5
NZ200-7R5G/11P-4 7.5 20 17 7.5
NZ200-11G/15P-4 11 26 25 11
NZ200-15G/18.5P-4 15 35 32 15
NZ200-18.5G/22P-4 18.5 38 37 18.5
NZ200-22G/30P-4 22 46 45 22
NZ200-30G/37P-4 30 62 60 30
NZ200-37G/45P-4 37 76 75 37
NZ200-45G/55P-4 45 90 90 45
NZ200-55G-4 55 105 110 55
NZ200-75G/90P-4 75 140 150 75
NZ200-90G/110P-4 90 160 176 90
NZ200-110G/132P-4 110 210 210 110
NZ200-132G/160P-4 132 240 253 132
... ... ... ... ...
NZ200-450G/500P-4 450 790 790 450





VFD Application

380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 0



VFD Packing

380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 1



VFD Company introduction

380v Inversor De Frecuencia 30hp 3phase AC Drives 22kw With CE From ZONCN Factory 2





FAQ

Q1: Is there braking unit in NZ200 series VFD inverters?

A:  Power between 3.7kw to 37kw all built in braking unit. 45kw and above is optional.



Q2: Can you guide us for the programming?

A: No problem, we can help you.

Q3. Can you produce for my own brand of VFD inverters?

A:  Sure, we have lots of experience for producing OEM logos.
