Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw

Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw
Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw
Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: KC; CE
Model Number: NZ100-1R5G-2
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, L/C, Western Union, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Product: Variable Frequency Inverter Brand: ZONCN
Model: NZ100-1R5G-2 Analog Input: 0-10V/4-20mA
Communication: RS485 Weight: 0.7kg
External Keyboard: Available Certificate: CE,KC
Cooling Mode: Forced Air Cooling Protection: IP20
Highlight:

380v Single Phase Inverter

,

Mini Single Phase Inverter

,

220v Single Phase Inverter

Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw





Why choose NZ100 series

Small size inverter with RS485 communication? ---Choose ZONCN NZ100 series inverter

Small power just for controlling speed? --- Choose ZONCN NZ100 series inverter

Need Analog input (0-10V/ 4-20mA)? --- ZONCN NZ100 series inverter have

Need external keypad for remote control?--- ZONCN NZ100 series inverter have

Use for fan/pump/conveyor/blower with V/F control?--- ZONCN NZ100 series inverter have good performance and price.

220v single phase input&output below 5.5kw?--- ZONCN NZ100 series inverter have.

Want OEM/ODM?--- ZONCN can produce for your own brand of inverter based on this series!





NZ100 inverter's Specification

VFD Model Input Voltage  Output Power (KW) Input Current (A) Output Current (A)  Motor Equipped (KW)
NZ100-0R4G-2 1PH AC220V+/-15% 0.4 5.4 2.5 0.4
NZ100-0R75G-2 0.75 8.2 5 0.75
NZ100-1R5G-2 1.5 14 7 1.5
NZ100-2R2G-2 2.2 23 11 2.2
NZ100-0R75G-4 3PH AC380V+/-15% 0.75 3.4 2.7 0.75
NZ100-1R5G-4 1.5 5.0 4.0 1.5
NZ100-2R2G-4 2.2 5.8 5.0 2.2
NZ100-3R7G-4 3.7 10.7 8.6 3.7
NZ100-5R5G-4 5.5 14.6 12.5 5.5
For powers above 5.5kw, NZ200 series with vector control is recommended.































VFD inverter's Dimension



Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw 0





VFD inverter's Wiring Diagram



Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw 1





Packaging

Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw 2





Application



Mini Inversor ZONCN 220v Single Phase Inverter 220v 380v VFD VSD 0.75kw 1.5kw 2.2kw 3.7kw 3













Tag:

Variable Frequency Drive Inverter,

vector control inverter,

low power inverter
