Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw

Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw
Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw
Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: KC; CE
Model Number: NZ100-1R5G-2
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, L/C, Western Union, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Product: Mini VFD Inverter Brand: ZONCN
Input: 1ph 220VAC Power: 2hp/1.5kw
Control Mode: V/F Control Frequency: 50hz/60hz
Analog Voltage Input: 0-10V Analog Current Input: 4-20mA
Communication: MODBUS Via RS485 PID Control: Built-in
Highlight:

0.75kw Mini Inverter VFD

,

1.5kw Mini Inverter VFD

,

220v Mini Inverter VFD

Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw



Mini size of ZONCN inverter NZ100 series, it is small size, space saving, V/F control mode ONLY, NZ100 series inverters are widely in small powers of fan, pump, converyors, blowers, food machines, etc to control the motor speed for saving engery.

  • Voltage: 220v 1ph; 380v 3phase
  • Power range: 0.4kw to 7.5kw
  • Frequency: 50hz/60hz
  • Output frequency: 0.1-400Hz
  • Analog voltage input: 1-10V
  • Analog current input: 0-20mA
  • Communication: RS485 MODBUS RTU
  • 220v single phase input, 220v single phase output, all support
  • Support OEM/ODM



VFD inverter's Specification

VFD Model Input Voltage  Output Power (KW) Input Current (A) Output Current (A)  Motor Equipped (KW)
NZ100-0R4G-2 1PH AC220V+/-15% 0.4 5.4 2.5 0.4
NZ100-0R75G-2 0.75 8.2 5 0.75
NZ100-1R5G-2 1.5 14 7 1.5
NZ100-2R2G-2 2.2 23 11 2.2
NZ100-0R75G-4 3PH AC380V+/-15% 0.75 3.4 2.7 0.75
NZ100-1R5G-4 1.5 5.0 4.0 1.5
NZ100-2R2G-4 2.2 5.8 5.0 2.2
NZ100-3R7G-4 3.7 10.7 8.6 3.7
NZ100-5R5G-4 5.5 14.6 12.5 5.5
For powers above 5.5kw, NZ200 series with vector control is recommended.































VFD inverter's Dimension



Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw 0





VFD inverter's Wiring Diagram



Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw 1





Packaging

Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw 2





Application



Mini Inverter VFD NZ100 Series Of ZONCN 220v 1ph Variable Frquency Drive 0.75kw 1.5kw 3
