Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: KC; CE
Model Number: NZ100-0R75G-2
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, L/C, Western Union, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Product: Mini VFD Inverter Brand: ZONCN
Input: 220V Single Phase Power: 0.75kw/1HP
Control Mode: V/F Control Output Currenct: 7A
Communication: MODBUS Via RS485 PID Control: Built-in
Highlight:

220v NZ100 Inverter

,

0.75kw NZ100 Inverter

,

1.5kw NZ100 Inverter

NZ100 Inverter 0.75kw 1.5kw 220v Single Phase Input VFD VSD 1hp 2hp From ZONCN





NZ100 is one of hottest selling series of ZONCN inverter, it is small size, space saving, V/F control mode, 220v single phase and 380v three phase both have, power range from 0.4kw to 7.5kw, output frequency range 0.1-400Hz with standard Modbus RTU, RS485 communication. It has analog input terminals (0-10V, 4-20mA). Built in-PID control. NZ100 series inverter are widely in small powers of fan, pump, converyors, food machines, etc to control the motor speed for saving engery.



VFD inverter's Specification

VFD Model Input Voltage  Output Power (KW) Input Current (A) Output Current (A)  Motor Equipped (KW)
NZ100-0R4G-2 1PH AC220V+/-15% 0.4 5.4 2.5 0.4
NZ100-0R75G-2 0.75 8.2 5 0.75
NZ100-1R5G-2 1.5 14 7 1.5
NZ100-2R2G-2 2.2 23 11 2.2
NZ100-0R75G-4 3PH AC380V+/-15% 0.75 3.4 2.7 0.75
NZ100-1R5G-4 1.5 5.0 4.0 1.5
NZ100-2R2G-4 2.2 5.8 5.0 2.2
NZ100-3R7G-4 3.7 10.7 8.6 3.7
NZ100-5R5G-4 5.5 14.6 12.5 5.5
For powers above 5.5kw, NZ200 series with vector control is recommended.































VFD inverter's Dimension



NZ100 Inverter 0.75kw 1.5kw 220v Single Phase Input VFD VSD 1hp 2hp From ZONCN 0





VFD inverter's Wiring Diagram



NZ100 Inverter 0.75kw 1.5kw 220v Single Phase Input VFD VSD 1hp 2hp From ZONCN 1









Application



NZ100 Inverter 0.75kw 1.5kw 220v Single Phase Input VFD VSD 1hp 2hp From ZONCN 2
