ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase

ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase
ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE, KC
Model Number: Z2200-0R75G-3
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: VFD Inverter Brand: ZONCN
Application: Motor Speed Control Series: Z2000
Input: 220V 3phase Protection: IP20
Braking Unit: Built-in Control Mode: Vector Control
Output Current: 3.7A Power Range: 0.4kw-450kw
Highlight:

3phase Variable Frequency Drive Inverter

,

220v Variable Frequency Drive Inverter

,

1hp Variable Frequency Drive Inverter





ZONCN Inverter 3phase 220v Variable frequency drives (VFD)











Inverter Features

Series Z2000 inverter

220v single phase input, 220v three phase output inverter

220v three phase input, 220v three phase output inverter

380v three phase input, 380v three phase output inverter

220v single phase input, 380v three phase output inverter

440v three phase input, 440v three phase output inverter

480v three phase input, 440v three phase output inverter

Power range: 0.4kw-450kw





VFD Inverter Specification

VFD inverter Specification
 Inverter Model Rated Output Power(kW) Rated Input Current(A) Rated Output Current(A) Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z2200-0R4G 0.4 5.4 2.5 0.4
Z2200-0R75G 0.75 7.2 5 0.75
Z2200-1R5G 1.5 10 7 1.5
Z2200-2R2G 2.2 16 11 2.2
Z2200-3R7G 3.7 23 16.5 3.7
Z2200-5R5G 5.5 21 25 5.5
Z2200-7R5G 7.5 31 32 7.5
Input Voltage:3PH AC 380V±15%
Z2400-0R75G 0.75 3.8 2.5 0.75
Z2400-1R5G 1.5 5 3.7 1.5
Z2400-2R2G 2.2 5.8 5 2.2
Z2400-3R7G/5R5P 3.7/5.5 10/15.0 9/13 3.7/5.5
Z2400-5R5G 5.5 15 13 5.5
Z2400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
Z2400-11G/15P 11/15 26/35 25/32 11/15
Z2400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
Z2400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
Z2400-22G/30P 22/30 46/62 45/60 22/30
Z2400-30G/37P 30/37 62/76 60/75 30/37
Z2400-37G/45P 37/45 76/90 75/90 37/45
Z2400-45G/55P 45/55 90/105 90/110 45/55
Z2400-55G 55 105 110 55
Z2400-75G/90P 75/90 140/160 150/176 75/90
Z2400-90G/110P 90/110 160/210 176/210 90/110
Z2400-110G/132P 110/132 210/240 210/253 110/132
Z2400-132G/160P 132/160 240/290 253/300 132/160
Z2400-160G/185P 160/185 290/330 300/340 160/185
Z2400-185G/200P 185/200 330/370 340/380 185/200
Z2400-200G/220P 200/220 370/410 380/420 200/220
… 　 　 　 　




*Note: If you have any special requirements for VFD inverter, pls feel free to contact us directly, we can customize for you.





VFD inverter Nameplate Description

ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase 0





Company Introduction

ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase 1

ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase 2









VFD inverter Application

ZONCN Variable Frequency Drive Inverter 1hp 0.75kw 220v 3phase 3

















Tag:

Variable Frequency Drive Inverter,

vector control inverter,

low power inverter
