Factory Price Of VFD Drives 380V 15kw 18.5kw 22kw Variable Speed Drives ZONCN Inverter

ZONCN 380v 440v 480v 15kw 18.5KW 22KW VFD





Company Introduction

ZONCN is a leading VFD drives manufacturer in China since 2005. Until now, our factory area is about 100,000 Square meters.Our VFD inverter's annual sales quantity has reached 1 Million units.  What's more, ZONCN was listed on the main board of the Shanghai Stock Exchange in August 2023(Stock Code 603275) .

We have our own R&D team, we keep upgrading the series of our VFDs, and to make the VFDs more better to use with lower cost. Currently, we have main series VFD, they are, NZ100, NZ200, Z2000, Z8000, T9000 and Z5000-BF, they are widely used all kinds of industry applications. And in air compressor industry, ZONCN takes Top 1 market share in China. Besides, we have produced for lots of OEM inverter brands both for domestic and abroad market.



VFD Specification

VFD Model	Input Voltage (V)	Rated output power ( KW)	Rated input current(A)	Rated output current (A)	Motor power ( KW)
NZ200-0R4G-2	1PH 220V±15%	0.4	5.4	2.5	0.4
NZ200-0R75G-2		0.75	7.2	5	0.75
NZ200-1R5G-2		1.5	10	7	1.5
NZ200-2R2G-2		2.2	16	11	2.2
NZ200-3R7G-2		3.7	17	16.5	3.7
NZ200-0R4G-4	3PH 380V±15%	0.4	3.4	1.2	0.4
NZ200-0R75G-4		0.75	3.8	2.5	0.75
NZ200-1R5G-4		1.5	5	3.7	1.5
NZ200-2R2G-4		2.2	5.8	5	2.2
NZ200-3R7G/5R5P-4		3.7	10.7	9	3.7
NZ200-5R5G/75R5P-4		5.5	14.6	13	5.5
NZ200-7R5G/11P-4		7.5	20	17	7.5
NZ200-11G/15P-4		11	26	25	11
NZ200-15G/18.5P-4		15	35	32	15
NZ200-18.5G/22P-4		18.5	38	37	18.5
NZ200-22G/30P-4		22	46	45	22
NZ200-30G/37P-4		30	62	60	30
NZ200-37G/45P-4		37	76	75	37
NZ200-45G/55P-4		45	90	90	45
NZ200-55G-4		55	105	110	55
NZ200-75G/90P-4		75	140	150	75
NZ200-90G/110P-4		90	160	176	90
NZ200-110G/132P-4		110	210	210	110
NZ200-132G/160P-4		132	240	253	132
...		...	...	...	...
NZ200-450G/500P-4		450	790	790	450





VFD Nameplate Description



VFD Dimension



A. 0.4kw-37kw







B. 45kw-450kw



VFD Packing



VFD Company introduction





FAQ

Q1: Can you guide us to install the VFD Drives?

A: Yes, no problem.





Q2: Do you provide any technical support for you VFDs?



A: If any techincal questions for our VFDs, you can feel free to contact us directly, we will help you by our engineers.

Q3. You have different series of VFD drives, how to choose the right model from your VFDs?

A: We can recommend you the approriate inverter series and VFD model if you can send us your application,voltage and motor power.

Q4: Do your VFDs have warranty?

A:  We provide warranty of 18 months, you can feel ease to use.
