220v To 380v 5.5kw 7.5kw Variable Frequency Drive ZONCN VFD Inverter 7hp 10hp

Basic Information

Place of Origin:	China
Brand Name:	ZONCN
Certification:	CE
Model Number:	Z2000-7R5G-24

Minimum Order Quantity:	1 PC
Packaging Details:	inside: box; outside: carton
Delivery Time:	7-30 days
Payment Terms:	T/T, Paypal
Supply Ability:	100,000 pcs/month

Get Best Price Contact Now

Type:	AC Frequency Inverter	Brand:	ZONCN
Model:	Z2000-7R5G-24	Frequency:	50/60HZ
Input:	220V 1 Phase	Output:	380v 3 Phase
Communication:	RS485	Control Mode:	V/F Control； Vector Control
Shipping:	By Express/Air/UPS	Voltage:	110v To 220v; 220v To 380v
Highlight:	10hp Variable Frequency Drive , 7.5kw Variable Frequency Drive , 380v Variable Frequency Drive

ZONCN Z2000 Series Boost Frequency Inverter

Product Features

Inverter type: Boost inverter
Control mode: V/F control + Vector control

Maximum frequency: V/F control 0-3200Hz; vector control: 0-600Hz
Input: 220v single phase; output: 380v three phase;
Power range: 0.4kw to 15kw
PID control: Built-in
Warranty: 18 months after delivery

Specification

220V 1PH input to 380V 3PH ouput	Model	Output Power(KW)	Capacity(KVA)	Rated Input Current(A)	Rated Output Current(A)
	Z2000-0R4G-24	0.4	0.8	3.7	1.2
	Z2000-0R75G-24	0.75	1.6	7.8	2.5
	Z2000-1R5G-24	1.5	2.5	11.8	3.8
	Z2000-2R2G-24	2.2	3.4	15.9	5.1
	Z2000-3R0G-24	3	4.7	22.4	7.2
	Z2000-3R7G-24	3.7	5.9	28	9
	Z2000-5R5G-24	5.5	8.6	40.5	13
	Z2000-7R5G-24	7.5	11.2	53	17
	Z2000-11G-24	11	16.5	77.9	25

Dimension

220v To 380v 5.5kw 7.5kw Variable Frequency Drive ZONCN VFD Inverter 7hp 10hp 0

Company Introduction

220v To 380v 5.5kw 7.5kw Variable Frequency Drive ZONCN VFD Inverter 7hp 10hp 2

ZONCN, Top 5 inverter manufacturer in China, which was established in 2006. ZONCN is focus on producing inverter and servo, we keep researching and developing different series, for example, NZ100, NZ200, Z2000, Z5000, T8000, T9000, SP500, SP600, DP500 etc., they are widely used in different applications, for example: fan and pump, printing and packaging, CNC, conveyor, textile machine, extrude machine, water treatment. What's more, ZONCN is the most famous brand which used in air compressor.
