220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485

220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485
220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485 220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD Inverter With RS485
Basic Information
Place of Origin: CHINA
Brand Name: ZONCN
Certification: CE
Model Number: NZ100
Minimum Order Quantity: 1
Packaging Details: Carton Packaging
Delivery Time: 7-10
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000
Get Best Price Contact Now
Model Number: NZ100-0R75G-2 Type: VFD Inverter
Condition: 100%new Product Name: VFD Drive
Control Mode: V/F Control Rated Power: 0.75kw
Nominal Voltage: 220v Material: Plastic Material
Pid: Build-in PID Control Vf Control: Support
Operating Temperature: -10℃-50℃ Output Frequency: 60Hz
Delivery: Within 15 Days Normally Communication Interface: RS485(MODBUS)
Output: 1ph 220V Series: NZ100
Size: Mini
Highlight:

0.75KW ZONCN NZ100 INVERTER

,

MULTIFUNCTIONAL INPUT ZONCN NZ100 INVERTER

,

LOW VOLTAGE ZONCN NZ100 INVERTER

220v 0.75kw 1.5kw 380v Variable Frequency Drive Mini VFD inverter With RS485



ZONCN NZ100 VFD Introduction



  • Mini size VFD, can use in small space
  • Low cost VFD, cheap price
  • V/F control VFD
  • Standard RS485 communication VFD
  • Voltage: 220v/380v
  • Power: 0.4kw-11kw
  • Potentionmeter is available
  • Remote keypad is available





VFD Products Description



 VFD Model Input Current(A) Output Power (kW) Capacity (KVA) Output Current (A) Overload capacity (60s)(A) Motor Equipped(kW)
Input Voltage(V):1PH AC 220V±15%
NZ100-0.4kw 5.4 0.4 1 2.5 3.75 0.4
NZ100-0.75kw 8.2 0.75 2 5 7.5 0.75
NZ100-1.5kw 14 1.5 2.8 7 10.5 1.5
NZ100-2.2kw 23 2.2 4.5 11 16.5 2.2
Input Voltage(V):3PH AC 380V±15%
NZ100-0.75kw 3.4 0.75 2.2 2.7 4.05 0.75
NZ100-1.5kw 5 1.5 3.2 4 6 1.5
NZ100-2.2kw 5.8 2.2 4 5 7.5 2.2
NZ100-3.7kw 10.7 3.7 6.8 8.6 12.9 3.7
NZ100-5.5kw 14.6 5.5 10 12.5 18.75 5.5
NZ200 series with vector control is recommended for those larger than 5.5kw





VFD inverter Applications:

  • Fan
  • Pump
  • Conveyor
  • blower
  • food machine
