ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive

ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive
ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: CE
Model Number: Z8400-3R7G
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: AC Inverters Brand: ZONCN
Series: Z8000 Series PM Motor: Support
Input Voltage: 3PH 380V+/-15% PID Control: On Board
PG Card: Support Communication: Profibus
Tension Control: Yes Control Mode: Close Loop Vector Control
Highlight:

VFD ZONCN Inverter

,

High Performance ZONCN Inverter

,

Variable Speed Drive ZONCN Inverter





ZONCN Z8000 Series High Performance Close Loop Vector Control









Product Features

  • The carrier frequency is automatically adjusted based on the load features;

  • Wide Frequency range, adapt to most applications;

  • V/F control

  • Close loop vector control

  • On board PID control

  • Modbus communication (Optional parts);

  • Support for various PG card; Special for kinds of industries, with tension control, spindle servo, support for PM motor ect.

  • Power range:220V 0.4kW~3.7kW; 380V 0.75kW~1000kW;  690V 11kW~1000kW



Product description

Item Z8000
Standard Function Control mode Senseless flux vector control(SFVC) ; Closed-loop vector control; V/F control
Maximum frequency Vector control: 0-320Hz ; V/F control: 0-3200Hz
Carrier frequency 1-16kHz ; The carrier frequency is automatically adjusted based on the load features
Input frequency solution Digital setting: 0.01Hz ; Analog setting: 0.025% of maximum frequency
Startup torque G type: 0.5Hz/150%(SFVC) ; 0 Hz/180% (CLVC)  P type: 0.5Hz/100%
Speed range 1:100 (SFVC);  1:1000 (CLVC)
Speed stability accuracy ±0.2% (SFVC); ±0.2% (CLVC)
Overload capacity G type: 60s for 150% of the rated current, 3s for 180% of the rated current. P type: 60s for 120% of the rated current, 3s for 150% of the rated current.
Torque boost Auto boost ; Customized boost 0.1%-30.0%
V/F curve Line V/F curve; Multi-point V/F curve; N-power V/F curve(1.2-power, 1.4-power, 1.6-power, 1.8-power, square)
V/F separation Two types: complete separation; half separation
Ramp mode Straight-line ramp ; S-curve ramp ; Four groups of acceleration/deceleration time with the range of 0.0-6500.0s
DC braking DC braking frequency : 0.0Hz to maximum frequency Braking time: 0.0~100.0s Braking action current value: 0.0%~100.0%
JOG control JOG frequency range: 0.00~50.00Hz JOG acceleration/deceleration time: 0.0~6500.0s
Onboard multiple preset speeds It implements up to 16 speeds via the simple PLC function or combination of terminal states.
Onboard PID It realizes process-controlled closed loop control system easily
Auto voltage regulation(AVR) It can keep constant output voltage automatically when the mains voltage changes.
Auto voltage/ Over current stall control The current and voltage are limited automatically during the running process so as to avoid frequent tripping due to overvoltage/over current
Rapid current limit It helps to avoid frequent over current faults of the AC drive
Torque limit and control It can limit the torque automatically and prevent frequent over current tripping during the running process. Toque control can be implemented in the CLVC mode.



Specification

Model Rated Output Power(kW) Rated Input Current(A) Rated Output Current(A) Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z8200-0R4G 0.4 5.4 2.5 0.4
Z8200-0R75G 0.75 7.2 5 0.75
Z8200-1R5G 1.5 10 7 1.5
Z8200-2R2G 2.2 16 11 2.2
Z8200-3R7G 3.7 23 16.5 3.7
Input Voltage:3PH AC 380V±15%
Z8400-0R75G 0.75 3.8 2.5 0.75
Z8400-1R5G 1.5 5 3.7 1.5
Z8400-2R2G 2.2 5.8 5 2.2
Z8400-3R7G/5R5P 3.7/5.5 10/15.0 9/13 3.7/5.5
Z8400-5R5G/7R5P 5.5 15 13 5.5
Z8400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
Z8400-11G/15P 11/15 26/35 25/32 11/15
Z8400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
Z8400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
Z8400-22G/30P 22/30 46/62 45/60 22/30
Z8400-30G/37P 30/37 62/76 60/75 30/37
Z8400-37G/45P 37/45 76/90 75/90 37/45
Z8400-45G/55P 45/55 90/105 90/110 45/55
Z8400-55G 55 105 110 55
Z8400-75G/90P 75/90 140/160 150/176 75/90
Z8400-90G/110P 90/110 160/210 176/210 90/110
Z8400-110G/132P 110/132 210/240 210/253 110/132
Z8400-132G/160P 132/160 240/290 253/300 132/160
Z8400-160G/185P 160/185 290/330 300/340 160/185
Z8400-185G/200P 185/200 330/370 340/380 185/200
Z8400-200G/220P 200/220 370/410 380/420 200/220
… 　 　 　 　
Z8400-1000G 1000 1800 1720 1000





Note: If you have any special requirements, pls feel free to contact us directly, we can customize for you.



Nameplate Description

ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive 0







Company Profile

ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive 1

ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive 2







Typical Wiring Diagram

ZONCN Inverter High Performance VFD Inverter 380v 440v 480v Variable Speed Drive 3
