0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive

0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive
0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive
Basic Information
Place of Origin: China
Brand Name: ZONCN
Certification: KC; CE
Model Number: Z2200-0R75G
Minimum Order Quantity: 1 PC
Packaging Details: inside: box; outside: carton
Delivery Time: 7-30 days
Payment Terms: T/T, Paypal
Supply Ability: 100,000 pcs/month
Get Best Price Contact Now
Type: AC Drive Brand: ZONCN
Input Voltage: 1PH 220V Output Frequency: 3PH 220V
Rated Power: 0.75kw/1hp Output Frequency: 50Hz/60Hz
OEM: YES Warranty: 18 Months
Highlight:

0.75kw 1.5kw Low Voltage Inverter

,

Low Voltage Inverter 1PH 220V



220v Single Phase Input Three Phase Output Frequency Inverter 0.75kw 1.5kw



VFD inverter Description

Inverter Model Input Voltage (V) Rated output power ( KW) Rated input current(A) Rated output current (A) Motor power ( KW)
NZ200-0R4G-2 1PH 220V±15% 0.4 5.4 2.5 0.4
NZ200-0R75G-2 0.75 7.2 5 0.75
NZ200-1R5G-2 1.5 10 7 1.5
NZ200-2R2G-2 2.2 16 11 2.2
NZ200-3R7G-2 3.7 17 16.5 3.7
NZ200-0R4G-4 3PH 380V±15% 0.4 3.4 1.2 0.4
NZ200-0R75G-4 0.75 3.8 2.5 0.75
NZ200-1R5G-4 1.5 5 3.7 1.5
NZ200-2R2G-4 2.2 5.8 5 2.2
NZ200-3R7G/5R5P-4 3.7 10.7 9 3.7
NZ200-5R5G/75R5P-4 5.5 14.6 13 5.5
NZ200-7R5G/11P-4 7.5 20 17 7.5
NZ200-11G/15P-4 11 26 25 11
NZ200-15G/18.5P-4 15 35 32 15
NZ200-18.5G/22P-4 18.5 38 37 18.5
NZ200-22G/30P-4 22 46 45 22
NZ200-30G/37P-4 30 62 60 30
NZ200-37G/45P-4 37 76 75 37
NZ200-45G/55P-4 45 90 90 45
NZ200-55G-4 55 105 110 55
NZ200-75G/90P-4 75 140 150 75
NZ200-90G/110P-4 90 160 176 90
NZ200-110G/132P-4 110 210 210 110
NZ200-132G/160P-4 132 240 253 132
... ... ... ... ...
NZ200-450G/500P-4 450 790 790 450



Specification

Inverter Specification
Model Rated Output Power(kW) Rated Input Current(A) Rated Output Current(A) Motor Equipped(kW)
Input Voltage:1PH or 3PH AC 220V±15%
Z2200-0R4G 0.4 5.4 2.5 0.4
Z2200-0R75G 0.75 7.2 5 0.75
Z2200-1R5G 1.5 10 7 1.5
Z2200-2R2G 2.2 16 11 2.2
Z2200-3R7G 3.7 23 16.5 3.7
Z2200-5R5G 5.5 21 25 5.5
Z2200-7R5G 7.5 31 32 7.5
Input Voltage:3PH AC 380V±15%
Z2400-0R75G 0.75 3.8 2.5 0.75
Z2400-1R5G 1.5 5 3.7 1.5
Z2400-2R2G 2.2 5.8 5 2.2
Z2400-3R7G/5R5P 3.7/5.5 10/15.0 9/13 3.7/5.5
Z2400-5R5G 5.5 15 13 5.5
Z2400-7R5G/11P 7.5/11 20/26 17/25 7.5/11
Z2400-11G/15P 11/15 26/35 25/32 11/15
Z2400-15G/18.5P 15/18.5 35/38 32/37 15/18.5
Z2400-18.5G/22P 18.5/22 38/46 37/45 18.5/22
Z2400-22G/30P 22/30 46/62 45/60 22/30
Z2400-30G/37P 30/37 62/76 60/75 30/37
Z2400-37G/45P 37/45 76/90 75/90 37/45
Z2400-45G/55P 45/55 90/105 90/110 45/55
Z2400-55G 55 105 110 55
Z2400-75G/90P 75/90 140/160 150/176 75/90
Z2400-90G/110P 90/110 160/210 176/210 90/110
Z2400-110G/132P 110/132 210/240 210/253 110/132
Z2400-132G/160P 132/160 240/290 253/300 132/160
Z2400-160G/185P 160/185 290/330 300/340 160/185
Z2400-185G/200P 185/200 330/370 340/380 185/200
Z2400-200G/220P 200/220 370/410 380/420 200/220
… 　 　 　 　





Company Introduction

0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 0

Wuhu Zoncn Automation Equipment Co., Ltd is one of a leading manufacturer focus on producing VFD inverter and servo products in China with 19 years of experience. We have 4 factories with headquarters in Shanghai, total factory area is 100,000 ㎡+, annual production capacity is about 1Million pcs. ZONCN has 6 mains series of VFDs: NZ100, NZ200, Z2000, Z8000, T9000, H5000 (IP65/54), etc. Our factory has passed ISO9001 quality control system and all the VFD inverters have CE certification.





The Inverter's voltage ranges from 110V to 1140V; power range covers 0.4kW to 1000Kw. Our VFD inverters are widely used in textile, print, CNC machine, food package, injection machine, fan, pump, air compressor, water treatment, industrial washing machine and many industrial applications.



Now our VFD inverters are exported to more than 50 countries in Asia, Europe, Africa and America. ZONCN will always dedicate in the field of VFD inverter drive and warmly welcome you to be our partner.



Exhibition

0.75kw 1.5kw Low Voltage VFD Inverter Single Phase 1HP 220V Variable Frequency Drive 1



Recommend series



FAQ

Q1. What is your Inverter's MOQ?

A: 1 unit.

Q2. What is the input voltage you can do for your VFD inverter?
A: 1PH/3H AC 220V+/-15%; 3PH AC 380V/440V/480V/690V

Q3. What is the power range you can do for your VFD inverter ?
A: From 0.4 kw to 1000 kw.

Q4. What is your terms of payment?
A: T/T 100% in advance.

Q5. What is your VFD inverter's delivery time?
A: Generally within15 days after receiving payment.

Q6. What is your VFD inverter's warranty period?
A. 18 months after delivery.
