20HP Low Voltage Inverter Vector Frequency Inverter high torque



20HP VFD vecot control low speed high torque variable speed drives ZONCN inverter

ZONCN NZ200 Series Econonic Vector control inverter







Inverter Nameplate Description

Inverter Specification

Model	Input Voltage (V)	Rated output power ( KW)	Rated input current(A)	Rated output current (A)	Motor power ( KW)
NZ200-0R4G-2	1PH 220V±15%	0.4	5.4	2.5	0.4
NZ200-0R75G-2		0.75	7.2	5	0.75
NZ200-1R5G-2		1.5	10	7	1.5
NZ200-2R2G-2		2.2	16	11	2.2
NZ200-3R7G-2		3.7	17	16.5	3.7
NZ200-0R4G-4	3PH 380V±15%	0.4	3.4	1.2	0.4
NZ200-0R75G-4		0.75	3.8	2.5	0.75
NZ200-1R5G-4		1.5	5	3.7	1.5
NZ200-2R2G-4		2.2	5.8	5	2.2
NZ200-3R7G/5R5P-4		3.7	10.7	9	3.7
NZ200-5R5G/75R5P-4		5.5	14.6	13	5.5
NZ200-7R5G/11P-4		7.5	20	17	7.5
NZ200-11G/15P-4		11	26	25	11
NZ200-15G/18.5P-4		15	35	32	15
NZ200-18.5G/22P-4		18.5	38	37	18.5
NZ200-22G/30P-4		22	46	45	22
NZ200-30G/37P-4		30	62	60	30
NZ200-37G/45P-4		37	76	75	37
NZ200-45G/55P-4		45	90	90	45
NZ200-55G-4		55	105	110	55
NZ200-75G/90P-4		75	140	150	75
NZ200-90G/110P-4		90	160	176	90
NZ200-110G/132P-4		110	210	210	110
NZ200-132G/160P-4		132	240	253	132
...		...	...	...	...
NZ200-450G/500P-4		450	790	790	450





Inverter Dimension



A. 0.4kw-37kw







B. 45kw-450kw

Inverter Packing



Inverter Workshop



Wuhu ZONCN is a professional manufacturer in the automation equipment industry, specializing in the production of inverters and servo products. With a rich experience of 19 years, ZONCN offers a wide range of inverter series including NZ100, NZ200, Z2000, Z8000, T9000, and Z5000-BF (IP65/IP54 protection). Our company is headquartered in Shanghai, with factories located in both Shanghai and Wuhu city, covering a total factory area of over 100,000 square meters. We have achieved an impressive annual sales quantity of 900,000+ units..

Wuhu ZONCN has many agents in both domestic and abroad markets. We also have lots of experience in providing OEM services. We have our own R&D team, we keep upgrading our inverter series to meet the market requirements. And we can customize according to customers' application requirements too. Fast delivery is one of our advantages, we keep stocks for standard inverter models, which can deliver within 15 days mostly.



Exhibition





Recommend Inverter Series







FAQ

Q1: What is your inverter's minimum order quantity (MOQ)?

A: Our MOQ is 1 PC.

Q2: Where are your factories located?

A: Our factories are located in Shanghai and Wuhu.

Q3: What is the warranty period for your inverters?

A: We offer an 18-month warranty period after delivery.

Q4: Do you provide OEM production services for inverter?

A: Yes, we have many experience in producing OEM brands.

Q5: How long is your inverter's delivery time?

A: Normally, our delivery time is within 15 days after receiving full payment.

Q6: What are your payment terms?

A: We accept 100% advance payment through T/T, PayPal, Trade Assurance by Alibaba, etc.

Q7: Do your inverters have CE certification?

A: Yes, all our inverters are CE certified.
