600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed

600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed
600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed 600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed 600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed
Basic Information
Place of Origin: Shanghai, China
Brand Name: ZONCN
Certification: CE
Model Number: T200-1R5G-2
Minimum Order Quantity: 1 unit
Packaging Details: Carton
Delivery Time: 7-30 work days
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 100000 units a month
Get Best Price Contact Now
Power: 1.5kw Voltage: 220v
Input: 50/60Hz Output: 600Hz
STO: Support Modbus: RS485
24V DC Power: Support
Highlight:

600Hz Low Voltage Inverter

,

Low Voltage Inverter Dc Vfd

,

Dc Vfd Drives 1500w

ZONCN T200 Series Low Voltage Variable Frequency Drives Ac Inverter 1500w for motor speed

T200 series 1.5kw inversor AC drives VFD

Basic product introduction:



ZONCN T200 series variable frequency drives offer several key advantages. They are cost-effective, making them an affordable choice for various applications. With their compact design, they are suitable for installations with limited space. The drives feature a user-friendly keyboard with an RJ45 interface, allowing for convenient operation and parameter adjustments. Additionally, the T200 series is equipped with an integrated EMC filter, effectively reducing electromagnetic interference. The drives also come with automatic voltage regulation, ensuring stable performance under different load conditions. Furthermore, they offer various protection functions, including overload, overcurrent, overvoltage, undervoltage, overheat, short circuit, and phase loss protection. Lastly, the T200 series supports PG cards, enabling precise speed and position control. Overall, the ZONCN T200 series variable frequency drives provide an economical, compact, and easy-to-install solution with a range of protective features and support for PG cards.





Technical characteristic:

600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed 0

600Hz Low Voltage 220V Inverter Ac Vfd Drives 1500w For Motor Speed 1





T200 model specifications:



Model Input voltage Rated output power(kw) Rated input current(A) Rated output current(A) Motor power(kw)
T200-0R4G-2 AC 1PH 220V± 15% 0.4 5.4 2.5 0.4
T200-0R75G-2 0.75 7.2 5.0 0.75
T200-1R5G-2 1.5 10.0 7.0 1.5
T200-2R2G-2 2.2 16.0 11.0 2.2
T200-0R4G-4



AC 3PH 380V±15%

 0.4 3.4 1.2 0.4
T200-0R75G-4 0.75 3.8 2.5 0.75
T200-1R5G-4 1.5 5.0 3.7 1.5
T200-2R2G-4 2.2 5.8 5.0 2.2
T200-3R0G-4 3.0 8.5 7.0 3.0
T200-3R7G/5R5P-4 3.7/5.5 10.0/15.0 9.0/13.0 3.7/5.5
T200-5R5G/7R5P-4 5.5/7.5 15.0/20.0 13.0/17.0 5.5/7.5
T200-7R5G/11P-4 7.5/11 20.0/26.0 17.0/25.0 7.5/11
T200-11G/15P-4 11/15 26.0/35.0 25.0/32.0 11/15
T200-15G/18.5P-4 15/18.5 35.0/38.0 32.0/37.0 15/18.5





Description of the T200 :

Maximum frequency:Vector control:0～600Hz V/F control:0-3200Hz

Control mode:Open loop vector control (no PG); Closed loop vector control (with PG)；V/F control
Carrier frequency:0.5kHz～16kHz；The carrier frequency can be automatically adjusted based on the load feature
Input frequency:resolution Digital setting:0.01Hz   Analog setting: maximum frequency×0.025%
Startup torque:G Type:0.5Hz/150%(SFVC)；P Type:0.5Hz/100%
Speed range:1:100(No PG)
Speed stability accuracy:±0.5%(No PG)
Torque control accuracy:±5%(FVC)
Overload capacity:G type: 60s for 150% of the rated current, 3s for 180% of the rated current P type: 60s for 120% of the rated current, 3s for 150% of the rated current
Torque boost:Fixed boost；Customized boost 0.1%-30.0%
V/F curve:Straight-line V/F curve；Multi-point V/F curve；N-power V/F curve (1.2-power, 1.4-power, 1.6- power,1.8-power, square)
V/F separation:Two types: complete separation; half separation
Ramp mode:Straight-line ramp；S-curve ramp；Four groups of acceleration/deceleration time with the range of 0.00-6500.0s
DC braking:DC braking frequency: 0.00 Hz to maximum frequency；Braking time: 0.0-100.0s；Braking action current value: 0.0%–100.0%
Onboard multiple preset speeds:It implements up to 16 speeds via the simple PLC function or by input terminal state


FAQ:

Q1: What is the minimum order quantity (MOQ) required?
A: The MOQ is set at 1 piece.



Q2: What are your payment terms?
A: We require 100% payment via T/T before delivery.



Q3: How long does it take for delivery?
A: Typically, the delivery time is within 15 days after receiving full payment.



Q4: How can I place an OEM/ODM order?
A: If your order quantity meets certain criteria, we are pleased to offer customization services. We have established partnerships with over forty manufacturers.



Tag:

Variable Frequency Drive Inverter,

vector control inverter,

low power inverter
