ZONCN NZ200-11G/15P-4 Low Voltage Inverter 380V 15HP 50/60Hz

Basic Information

Place of Origin:	Shanghai, China
Brand Name:	ZONCN
Certification:	CE
Model Number:	NZ200-11G/15P-4

Minimum Order Quantity:	1 unit
Packaging Details:	Carton packing；
Delivery Time:	7-30 work days
Payment Terms:	T/T, Western Union，Paypal
Supply Ability:	100000 units a month

Get Best Price Contact Now

Model:	NZ200-11G/15P-4	Input Frequency:	50-60Hz
Output Frequency:	Maximum 600Hz	Warranty:	18 Months Warranty
LED Display Removable:	Support External	DC Braking:	Support
Highlight:	Low Voltage Inverter 15HP , Low Voltage Inverter 50 60Hz

ZONCN NZ200-11G/15P-4 380V Inverter Motor Drive 15HP low voltage frequency inverter 50/60Hz

NZ200 11KW Economical Vector Control Inverter

Product Brief Introduction:

The NZ200 series inverter is a high-performance and user-friendly device. It is known for its simplicity in structure, easy installation, and cost-effectiveness. The NZ200 series inverter offers both open-loop vector control and VF control, providing excellent overload capacity and delivering high torque output to ensure smooth motor operation even under heavy loads. It is equipped with features like instant stop and quick current limiting, reducing the probability of inverter faults. Additionally, it comes with various protection functions such as overheat protection and overvoltage protection, ensuring the safety and reliability of the system. Overall, the NZ200 series inverter is a reliable and efficient solution that meets the requirements of a wide range of applications.

NZ200 Technical Specification:

Item		ZONCN NZ200 Series
Control Mode	Sensorless flux vector control(SFVC) Voltage/Frequency (V/F) Control
Maximum frequency	Vector control:0-320Hz V/F control:0-3200Hz
Carrier frequency	1kHz~16kHz The carrier frequency is automatically adjusted based on the load features.
Input frequency resolution	Digital setting:0.01Hz Analog setting: Maximum frequency 0.025%
Start torque	G: Type:0.5Hz/150%(SVC) P: Type:0.5Hz/100%
Speed range	1:100(SVC)
Speed stability accuracy	±0.5%(SVC)
Overload capacity	G Type:60s for 150% of the rated current, 3s for 180% of the rated current. P Type:60s for 120% of the rated current, 3s for 150% of the rated current.
Torque boost	Auto-boost ; Customized boost:0.1%~30.0%
VF curve	Straight-line VF curve; Multi-point VF curve; N-power VF curve(1.2-power,1.4-power,1.6-power,1.8-power, 2-power)
VF separation	2 types: complete separation；half separation
Ramp Mode	Straight-line ramp；S-curve ramp；Four groups of acceleration/deceleration time:0~6500.0s
Simple PLC, Multiple preset speeds	It implements up to 16 speeds via the simple PLC function or combination of terminal states
Auto voltage regulation(AVR)	It can keep constant output voltage automatically when the mains voltage changes
Rapid current limit	It helps to avoid frequent over current faults of the AC drive.
Torque limit and control	It can limit the torque automatically and prevent frequent over-current tripping during the running process.
Onboard PID	It realizes process-controlled closed loop control system easily
Rapid current limit	It helps to avoid frequent over current faults of the AC drive.
JOG control	JOG frequency range: 0.00–50.00 Hz JOG acceleration/deceleration time: 0.0–6500.0s
DC braking	DC braking frequency:0.00Hz to maximum frequency Braking time:0.0-100.0s Braking action current value:0.0%-100.0%
Instantaneous blackout doesn’t stop	The load feedback energy compensates the voltage reduction so that the AC drive can continue to run for a short time.
Timing control	Timing range:0.0Min~6500.0Min
Communication	RS485
Run instruction channel	Keyboard given, control terminal given, serial communication port given. It can be switched in a variety of ways.
Frequency source	10 kinds: digital given, analog voltage given, analog current given, pulse given, serial port given. It can be switched in a variety of ways.
Auxiliary frequency source	10 auxiliary frequency sources. It can flexibly realize auxiliary frequency fine-tuning and frequency synthesis.
Input terminals	6 digital input terminals, one of which supports up to 100 kHz high-speed pulse input (S3 optional). 2 analog input terminal, one of which only supports 0-10v voltage input(FIV) and the other supports 0-10 voltage input or 4-20 mA current input(FIC).
Output terminals	1 digital output terminal(MO1) 1 relay output terminal(RA,RB,RC) 1 analog output terminal :that supports 0-20 mA current output or 0-10v voltage output(FOV)
Remark	X terminal is NPN type by default. If PNP type is required, contact customer service for customization.
LED display	Not removable. More than 45kw is acceptable.
Keystroke locking and function selection	Realize partial or full lock of keys, and define the scope of action of some keys to prevent false touch
Multiple protection modes	Motor short-circuit detection at power-on, output phase loss protection, over-current protection, over-voltage protection, under voltage protection, overheat protection and overload protection.

Product Description:

FAQ:

1,What is your MOQ?
1 PC.

2,What is terms of payment?
T/T 100% before delivery.

3,What is your delivery time?
Fast delivery is our advantage. Usually within ten days.

4,How can we do OEM/ODM?
We do OEM for more than 40 brands. If your order reaches a certain quantity, we can do it for you.
