Variador De Velocidad ZONCN T200 Series Vfd Drive For Motor Low Voltage 220v

Basic Information

Place of Origin:	Shanghai, China
Brand Name:	ZONCN
Certification:	CE
Model Number:	T200-3R7G/5R5P-4

Minimum Order Quantity:	1 unit
Packaging Details:	Carton
Delivery Time:	7-30 work days
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	100000 units a month

Get Best Price Contact Now

Material:	Plastic	Voltage:	380v±15%
Protection:	IP20	Frequency Range:	0-600Hz
Rated Power:	3.7kw	Rated Input Current（A）:	10.0/15.0
Rated Output Current（A）:	9.0/13.0
Highlight:	3 Phase Frequency Inverter 380V , 3 Phase Frequency Inverter 3.7kw

Low Voltage 380V 3.7kw T200 AC frequency inverter build-in EMC filter 50/60Hz

T200 high performance AC drive Inverter

Basic product introduction:

· Cost effective；Micro compact design.

· Build-in EMC filter,24v DC power resource

· RS485,Ethercat,Profibus DP,CAN is optional

· VF control；Sensorless flux vector control

· Digital I/O；Integrated safety-safe torque off feature

Technical characteristic:

Maximum frequency	Vector control:0～600Hz；V/F control:0-3200Hz
Control mode	V/F control；Senseless flux vector control(SFVC); Closed loop vector control (CLVC)
Carrier frequency	0.5kHz～16kHz；The carrier frequency can be automatically adjusted based on the load feature
Input frequency resolution	Digital setting:0.01Hz；Analog setting: maximum frequency×0.025%
Startup torque	G Type:0.5Hz/150%(SFVC)；P Type:0.5Hz/100%
Speed range	1:100(No PG)
Speed stability accuracy	±0.5%(No PG)
Torque control accuracy	±5%(FVC)
Overload capacity	G type: 60s for 150% of the rated current, 3s for 180% of the rated current；P type: 60s for 120% of the rated current, 3s for 150% of the rated current
Torque boost	Fixed boost；Customized boost 0.1%-30.0%
V/F curve	Straight-line V/F curve；Multi-point V/F curve； N-power V/F curve (1.2-power, 1.4-power, 1.6- power,1.8-power, square)
V/F separation	Two types: complete separation; half separation
Ramp mode	Straight-line ramp；S-curve ramp Four groups of acceleration/deceleration time with the range of 0.00-6500.0s
DC braking	DC braking frequency: 0.00 Hz to maximum frequency Braking time: 0.0-100.0s Braking action current value: 0.0%–100.0%
JOG control	Jog frequency range:0.00Hz~50.00Hz. Jog acceleration/deceleration time0.0s~6500.0s
Onboard multiple preset speeds	It implements up to 16 speeds via the simple PLC function or by input terminal state
Onboard PID	It realizes process-controlled closed loop control system easily
Input terminals	5 digital input terminals, one of which supports up to 100 kHz high-speed pulse input; 1 analog input terminal, supports 0-10V voltage input or 4–20 mA current input.
Output terminals	1 digital output terminal 1 relay output terminal 1 analog output terminal : that supports 0–20 mA current output or 0–10 V voltage output
Protection mode	Motor short-circuit detection at power-on, input output phase loss protection, over-current protection, over-voltage protection, under voltage protection, overheat protection and overload protection.
Key locking and function selection	It can lock the keys partially or completely and define the function range of some keys so as to prevent mis-function.
LED display	It displays the parameters

T200-3R7G/5R5P-4 current parameter:

Model	Input voltage	Rated output power(kw)	Rated input current(A)	Rated output current(A)	Motor power(kw)
T200-3R7G/5R5P-4	380V±15%	3.7	10.0/15.0	9.0/13.0	3.7

T200 series product circuit diagram:

Variador De Velocidad ZONCN T200 Series Vfd Drive For Motor Low Voltage 220v 0

Product front structure:

Variador De Velocidad ZONCN T200 Series Vfd Drive For Motor Low Voltage 220v 1

Product application:

Variador De Velocidad ZONCN T200 Series Vfd Drive For Motor Low Voltage 220v 2

FAQ:

Q1:What is your MOQ?
A: 1 pc

Q2:What's your terms of payment?
A:T/T 100% before delivery.

Q3:What's your delivery time?
A:Generally within 15 days after receiving full payment.

Q4:How can l get OEM/ODM order?
A:If your order quantity meets certain requirements, we are happy to customize it for you. We have cooperation with more than forty manufacturers.
